The Altitude Powerplay set the standard for how to bring cutting-edge power to an aggressive trail bike, and it's still turning heads. Known for its precise handling and ride quality, this capable e-bike will have you riding more, faster, farther.
We took attributes from our race-winning Altitude platform and integrated the Dyname 3.0 drive system to create a groundbreaking new e-bike for riders around the world. With 27.5" wheels, 150mm of rear travel with optimized suspension kinematics, and 108 Nm of class-leading torque, the Altitude Powerplay is an e-bike that rides like a normal mountain bike. It's perfect for self-shuttling your way up and down the mountain, pushing it hard on the descent, and squeezing in that extra lap.
- Sleek, fully integrated design
- Intuitive & smooth Dyname 3.0 electric assist
- Super high torque drive output: 108Nm!
- High capacity 672 Wh battery
- Fast charging: from empty - 530 Wh (80%) in 2:10 hrs, 640Wh (95%) in 2:55, 100% in 3:50
- New iWoc Trio V3 with ANT+ communication for Garmin connectivity
- All new Fox 36 drops weight & adds air bleed ports
- New Shimano I-Spec EV brakes for an uncluttered cockpit
- Ergon grips to reduce rider fatigue
- Race Face Aeffect R post with Shimano remote
Dyname 3.0 drive
Designed in Canada, in collaboration with Propulsion Powercycle, the Dyname 3.0 drive system is a sleek, lightweight, and powerful electric assist that pushes the boundaries of electric bikes. Its compact, low-mounted motor allows us to design electric mountain bikes to our suspension and handling standards—with proper geometry and ideal pivot placement. The system provides class-leading torque, instant power response, and super-fast charging.
Size Specific tune
Size Specific Tune ensures that riders of all sizes get the right balance of small-bump compliance, mid-stroke support, and end-stroke progressiveness. Our design team does custom shock tunes based on real-world field testing and adjusts each tune for specific frame sizes.
ABC pivots are light and stiff. Unlike other bushings, our patented system controls the contact of the bushing surfaces, reducing stiction and binding. Their angled bushing surfaces increase their relative contact area, optimizing them for compact locations like chainstay pivots.
RIDE-9 adjustment system
The RIDE-9 adjustment system allows riders to quickly fine-tune their geometry and suspension with a pair of Allen keys. Nine configurations are possible thanks to two interlocking chips.
Adjust your RIDE-9 position for geometry before considering suspension effects, or variables like air pressure and shock compression. Make gradual, incremental changes, take notes and be methodical. Don't adjust in a hurry before a big ride. Take your time and enjoy the process.
Smoothlink suspension is efficient yet supple when you're on the pedals and across a wide range of gears. It features a controlled end-stroke and a rate-curve that feels more capable than the travel would suggest. This four-bar suspension design philosophy is centered on ride characteristics; each bike platform we develop balances variables like anti-squat, axle path, chain growth, rate curve, anti-rise, etc. to achieve the legendary Rocky Mountain ride feel.
Smoothwall carbon uses one of the world's most sophisticated carbon processes to deliver industry-leading stiffness-to-weight, ride quality, and durability. We eliminate excess resin and fibers by using rigid internal molds instead of traditional air bladders. We then utilize different types of carbon in specific frame areas to maximize stiffness and impact resistance while minimizing overall weight.
|Motor||Dyname 3.0 Class 1 eMTB Drive | 250w | 108Nm | Upgraded High Cadence Boost & Power Extension Firmware|
|Battery||672 Wh Fully Integrated Li-Ion | 48V FAST Charger | 80% Charge in 2:10 | 100% Charge in 3:50|
|Display||iWoc TRIO V3 Remote w. ANT+ LEV communication|
|Charger||48V FAST Charger|
|Frame||FORM Alloy. Full Sealed Cartridge Bearings. Press Fit BB89.5. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-9™ Adjustable Geometry + Suspension Rate. 150mm Travel. FORM Alloy Rear Triangle|
|Fork||Fox 36 Float EVOL GRIP Performance Series 160mm | 37mm Offset|
|Headset||FSA Orbit NO.57E | 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race|
|Rear Shock||Fox Float DPS Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | 210x55mm|
|Rims/Wheels||WTB ST i30 TCS 2.0 Tubeless | Tubeless Ready - Tape | Valves Incl | 32H|
Front: Shimano MT410 | 15mm Boost
Rear: Shimano M510 Boost 148mm | RMB Axle | 163mm x 12mm x 1.5mm
|Spokes||DT Swiss Champion 2.0|
Front: Maxxis Minion DHF 2.5 WT 3C MaxxGrip DD Tubeless Ready
Rear: Maxxis Aggressor WT Double Down Tubeless Ready 27.5 x 2.5
|Crankset||Race Face Ride Cinch 34T | 24mm Spindle | 170mm Crank Length|
|Bottom Bracket||Shimano SM-BBMT500|
|Rear Derailleur||Shimano SLX|
|Cassette/Rear Cogs||Shimano SLX 10-51T|
|Handlebars||Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35mm Clamp|
|Tape/Grips||Ergon GE10 EVO Lock On|
|Stem||Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m|
|Brakes||Shimano 6120 Trail 4 Piston | Metal Pads | RT64 203mm F Rotor | RT64 203mm R Rotor|
|Saddle||WTB Volt Race | Cromoly Rails | 142mm Width|
|Seat Post||Race Face Aeffect R Dropper 30.9mm | Shimano MT500 Remote | SM = 125mm | MD - LG = 150mm | XL = 175mm|
* Subject to change without notice.
|Beige/Purple / Small||770416295092||B0144SM1CA||202289215530|
|Beige/Purple / Medium||770416295191||B0144MD1CA||20230357868D|
|Beige/Purple / Large||770416295290||B0144LG1CA||2023044659G|
|Beige/Purple / X-Large||770416295399||B0144XL1CA||20236141410U|
